Amiad Automatic filter, type Mini Sigma Angle
£2,495.00£2,700.00 Select options

Amiad Automatic filter, type Mini Sigma Angle

£2,495.00£2,700.00

The Amiad Mini Sigma for Angle installations.

Amiad ADI-P 12VDC controller with a 2W-Latch solenoid allows the user to monitor and control the filter from the Amiad app on your mobile via Bluetooth.

The app will provide the following information:

– DP and flush cycle counters.

– Alerts (low/high pressures) and low battery.

– Reports and performance history data.

Self-cleaning cycle is triggered by an integrated DP switch which is initiated by: a Pre-set 0.5 signal from DP switch, a time interval or a manual start.

Flushing time of 10 seconds.

Delivered with 1.5” flush valve.

Clear
☑ Free UK delivery for orders over £300 (exc VAT)

Amiad Automatic filter, type Mini Sigma Angle

fibreglass-reinforced nylon, Mini Sigma Angle, stainless steel 316

The Amiad Mini Sigma for Angle installations.

Amiad ADI-P 12VDC controller with a 2W-Latch solenoid allows the user to monitor and control the filter from the Amiad app on your mobile via Bluetooth.

The app will provide the following information:

– DP and flush cycle counters.

– Alerts (low/high pressures) and low battery.

– Reports and performance history data.

Self-cleaning cycle is triggered by an integrated DP switch which is initiated by: a Pre-set 0.5 signal from DP switch, a time interval or a manual start.

Flushing time of 10 seconds.

Delivered with 1.5” flush valve.

7028316

Connection flange

Material fibreglass-reinforced nylon

Material filter element stainless steel 316

Pressure8 bar

Backflush Outlet1 1/2 “

Type Mini Sigma Angle

SizeDN80

Capacity50 m³/h

Filtration130 micron

Filter area1.6 m²

Voltage9-12VDC latch

Connection flange

Material fibreglass-reinforced nylon

Material filter element stainless steel 316

Pressure8 bar

Backflush Outlet1 1/2 “

Type Mini Sigma Angle

SizeDN100

Capacity80 m³/h

Filtration130 micron

Filter area2.4 m²

Voltage9-12VDC latch

Additional information

Size

DN80, DN100
