ESPA: Acuaria17 Submersible Multi Stage Pump – For open wells Pumping System UK
Submersible multi-stage pump for open wells with a minimum diameter of 140 mm. Double mechanical seal in oil bath.
Irrigation and hydropneumatic sets. Max. immersion level according to technical table, code 2240.
Outer casing, motor casing, impellers and filter in stainless steel AISI 304.
Motor shaft and pump shaft in stainless steel AISI 303.
Diffusers in tecnopolimer.
Double mechanical seal, in ceramic/graphite/NBR.
Discharge body in stainless steel AISI 304.
